Key:Carton Packer,Case Packer,wrap around case packer
A carton packer is a type of case equipment used to automatically erect, pack, close, and seal cases or trays. Case packers can be used pneumatically, mechanically, or robotically with a pick-and-place process.
Carton Packer Total：12 products
| CX-50T |
| Power supply | 380V±10%/50Hz,9.0KW (Three-phase four-wire system) |
| Air pressure | 3-6g/cm2 |
| Working speed | 50 cases/min |
| CX-100T |
| Power supply | 380V±10%/50Hz,9.0KW (Three-phase four-wire system) |
| Air pressure | 3-6g/cm2 |
| Working speed | 100 cases/min |
| CX-20T |
| Power supply | 380V±10%/50Hz,9.0KW (Three-phase four-wire system) |
| Air pressure | 4-7g/cm2 |
| Working speed | 15 cases/min |
| CX-35T |
| Power supply | 380V±10%/50Hz,9.0KW (Three-phase four-wire system) |
| Air pressure | 3-6g/cm2 |
| Working speed | 35 cases/min |
| CX-30TH |
| Tray Former Machine |
| Power supply |
3P 380V 50Hz,0.75KW 5-7kw(including hot melt glue machine) |
| Air pressure |
4-6kg/cm2 |
| Hot glue machine |
Nordson |
| Working speed |
15-25 trays/min(depends on tray size) |
| percent of pass (erecting trays) |
≥99.5% |
| Tray size |
Depends on the customer's tray |
| Worktable height |
Can be custom-made |
| Paper sheet storage frame |
150-300pcs(can be custom-made0 |
| With Alarm function |
With alarm functions of lacking hot glue(hot melt glue machine)
and paper sheet(main machine) |
| Machine outside size |
L1850×w1300×h2040mm(as reference) |
| Machine net weight |
1000kgs(will be different depengding on different products) |
| Envieonment temperature |
PLC:"Siemens" Touch screen:"Siemens" Servo motor: "Siemens" Cylinder:"Airtac" or "Festo" Sucker:"Youngsun" or "SMC" or "Festo" Contactor:"Schneider" transducer:"Schneider" Sensor:"P+F" |
| Working process |
Suck paper sheet-conveyor(spraying hot glue)-compression molding-output(erected trays) |
| ZX-10T |
| Wrap Around Carton Box Machine |
| Power supply |
3P AC380V+10% 50Hz 10KW |
| Hot Melt system |
4KW NORDSON |
| Air pressure |
0.6 MPa-0.8 MPa |
| Control voltage |
24V DC |
| Protection lever |
electric appliance cabinet IP54/push button IP65/low voltage electric element IP67 |
| Worktable |
customer order |
| Air consumption |
150L/min |
| Machine size |
L5571mm×W1512mm×H1700mm |
| Packing speed |
10pcs/min |
| Working noise |
≤75DB |
| Environmental condition |
Humiditiy≤98%,Temperature20-40℃ |
| PLC:Siemens |
"YOUNGSUN" touchscreen |
Transformer:Schneider |
| Programmable controller:Siemens |
Electrical magnetic valve:Festo |
Pneumatic element: Airtac/SMC/Festo |
| Transducer:Schneider |
Bearing:HRB |
Servo motor:Siemens |
| Proximity switch and photo electricity switch:P+F |
| Contactor,electrical relay, disconnector,pushbutton:Schneider |
| ZX-15T |
| Wrap Around Carton Box Machine |
| Power supply |
3P AC380V+10% 50Hz 11KW |
| Hot Melt system |
4KW NORDSON |
| Air pressure |
6-8kg/cm |
| Control voltage |
24V DC |
| Protection lever |
electric appliance cabinet IP54/push button IP65/low voltage electric element IP67 |
| Worktable |
customer order |
| Air consumption |
150L/min |
| Machine size |
L10394mm×W2400mm×H2541mm |
| Packing speed |
15pcs/min |
| Working noise |
≤75DB |
| Environmental condition |
Humiditiy≤98%,Temperature20-40℃ |
| PLC:Siemens |
"YOUNGSUN" touchscreen |
Transformer:Schneider |
| Programmable controller:Siemens |
Electrical magnetic valve:Festo |
Pneumatic element: Airtac/SMC/Festo |
| Transducer:Schneider |
Bearing:HRB |
Servo motor:Siemens |
| Proximity switch and photo electricity switch:P+F |
| Contactor,electrical relay, disconnector,pushbutton:Schneider |
| ZX-20T |
| Wrap Around Carton Box Machine |
| Power supply |
3P AC380V+10% 50Hz 10KW |
| Hot Melt system |
4KW NORDSON |
| Air pressure |
5-7kg/cm |
| Control voltage |
24V DC |
| Protection lever |
electric appliance cabinet IP54/push button IP65/low voltage electric element IP67 |
| Worktable |
customer order |
| Air consumption |
150L/min |
| Machine weight |
4000kg |
| Machine size |
L7550mm×W2650mm×H1900mm |
| Packing speed |
17pcs/min |
| Working noise |
≤75DB |
| Environmental condition |
Humiditiy≤98%,Temperature20-40℃ |
| PLC:Siemens |
"YOUNGSUN" touchscreen |
Transformer:Schneider |
| Programmable controller:Siemens |
Proximity switch and photo electricity switch:P+F |
Electrical magnetic valve:Festo |
| Transducer:Schneider |
Bearing:HRB |
Servo motor:Siemens |
| Cylinder and pneumatic components:Airtac/SMC/Festo |
| Contactor,electrical relay, disconnector,pushbutton:Schneider |
| ZX-30T |
| Wrap Around Carton Box Machine |
| Power supply |
3P AC380V+10% 50Hz 12.5KW |
| Hot Melt system |
4KW NORDSON |
| Air pressure |
6-8kg/cm |
| Control voltage |
24V DC |
| Protection lever |
electric appliance cabinet IP54/push button IP65/low voltage electric element IP67 |
| Worktable |
customer order |
| Air consumption |
150L/min |
| Machine weight |
5000kg |
| Machine size |
L7550mm×W2650mm×H2100mm |
| Packing speed |
25pcs/min |
| Working noise |
≤75DB |
| Environmental condition |
Humiditiy≤98%,Temperature20-40℃ |
| PLC:Siemens |
"YOUNGSUN" touchscreen |
Transformer:Schneider |
| Programmable controller:Siemens |
Proximity switch and photo electricity switch:P+F |
Electrical magnetic valve:Festo |
| Transducer:Schneider |
Bearing:HRB |
Servo motor:Siemens |
| Cylinder and pneumatic components:Airtac/SMC/Festo |
| Contactor,electrical relay, disconnector,pushbutton:Schneider |
| ZX-35T |
| Wrap Around Carton Box Machine |
| Power supply |
3P AC380V+10% 50Hz 17.96KW |
| Hot Melt system |
4KW NORDSON |
| Air pressure |
6-8kg/cm |
| Control voltage |
24V DC |
| Protection lever |
electric appliance cabinet IP54/push button IP65/low voltage electric element IP67 |
| Worktable |
customer order |
| Air consumption |
150L/min |
| Machine weight |
7000kg |
| Machine size |
L9700mm×W2200mm×H2000mm |
| Packing speed |
35pcs/min |
| Working noise |
≤75DB |
| Environmental condition |
Humiditiy≤98%,Temperature20-40℃ |
| PLC:Siemens |
"YOUNGSUN" touchscreen |
Transformer:Schneider |
| Programmable controller:Siemens |
Proximity switch and photo electricity switch:P+F |
Electrical magnetic valve:Festo |
| Transducer:Schneider |
Bearing:HRB |
Servo motor:Siemens |
| Cylinder and pneumatic components:Airtac/SMC/Festo |
| Contactor,electrical relay, disconnector,pushbutton:Schneider |
| ZX-40T |
| Wrap Around Carton Box Machine |
| Power supply |
3P AC380V+10% 50Hz 17KW |
| Hot Melt system |
4KW NORDSON |
| Air pressure |
0.4MPa-0.6MPa |
| Control voltage |
24V DC |
| Protection lever |
electric appliance cabinet IP54/push button IP65/low voltage electric element IP67 |
| Worktable |
1100mm(customer order) |
| Air consumption |
90L/min |
| Machine weight |
5000kg |
| Machine size |
L9233mm×W1790(3700)mm×H2562mm |
| Packing speed |
40pcs/min |
| Working noise |
≤75DB |
| Environmental condition |
Humiditiy≤98%,Temperature20-40℃ |
| PLC:Siemens |
Touch screen:Siemens |
Transformer:Schneider |
| Programmable controller:Siemens |
Proximity switch and photo electricity switch:P+F |
Electrical magnetic valve:SMC |
| Transducer:Danfoss |
Bearing:HRB |
Servo motor:Siemens |
| Cylinder and pneumatic components:SMC |
| Contactor,electrical relay, disconnector,pushbutton:Schneider |
| ZX-60T |
| Wrap Around Carton Box Machine |
| Machine Size |
L12944×W1790(3700)×H2562 |
| Max working speed |
55packs/min |
| Air consumption |
90L/min |
| Air pressure |
4-6Kgf/cm2 |
| Bottle Dimension |
0.25~1.5Liter |
| Power supply and voltage |
17Kw,hot melt glue machine:4Kw |
| Working noise |
≤75DB |
| Environmental condition |
Humiditiy≤98%,Temperature20-40℃ |
| PLC:Siemens |
Touch screen:Siemens |
Button:Schneider |
| Servo Motors:Siemens |
Motor:SEW、MEIWA |
Servo driver:Siemens |
| Contactor:Schneider |
Transducer:Schneider |
Relay:Schneider |
| Hot melt glue macine:Nordson |
Cylinder and pneumatic components:SMC |
| Proximity seitch and photo electricity switch:P+F |
